11
provides a jumper to disable the password protection temporary. This
jumper can be accessed only when the module’s plastic cover is removed.
The relative location of jumper is depicted at follow:
JP1
NO PASS
When the jumper cap of JP1 is at upper position (linked by white line), the
password protection is disabled. The jumper cap should put in the lower
position when under normal operation.
5.2.2 Cable Wiring
Serial port connectors:
Please refer Appendix A, B for the Port3, Port4 signal description.
Network connector:
The connector type of FBs-CM25E/55E is Euro 4pin plug connector while
FBs-CBE board is RJ-45.
Please use the CAT5 UTP (un-shielded twisted pair) cable for network
connection. The best recommendation is using the CAT5 STP(shielded
twisted pair) cable。
The wiring of cable to network connector is listed as below.
Signal Wire Color
Euro-4 Pin RJ-45
Direction
TX+ White-Orange 3 1
Output←
TX- Orange 4 2
Output←
RX+ White-Green 1 3
Input→
RX- Green 2 6
Input→
