1. Preface
The network communication with its flexible connectivity and mobility can
easily penetrate the barrier of the information island. Though at early
days, most of the network systems are deployed in commercial
environment, but as the evolution of the manufacture technology, the
requirement of CIM/CAM is prevailing. To reach this goal how to provide a
reliable and accessible medium is a key. Because the network
communication has the characteristics as demand, so can be found
nowadays in the industrial segment and used to bridge the communication
between the management level and field level. To meet this trend, FATEK
provides a series of Network interface modules, with which an economic
and effective network solution for FATEK FBs-PLC can be obtained.
Besides the network function, some of the modules also provide an
additional serial communication port for application.
2. Specification
2.1 Serial Communication Connector(FBs-CM25E/CM55E only)
2.2
Module
Port Signal Type Connector Power
1
port3 RS232 DB9M
port4 RS485 Euro. 3pin Con.
FBs-CM25
Ethernet 10BaseT Euro. 4pin Con.
200ma
port3 RS485 Euro. 3pin Con.
port4 RS485 Euro. 3pin Con.
FBs-CM55
Ethernet 10BaseT Euro. 4pin Con.
200ma
FBs-CBE
Ethernet 10BaseT RJ45 150ma
Note 1: Powered by CPU module
