Favero ASSIOMA UNO User Manual

3
FAVERO Electronics - 0259-0902A Assioma user manual _Rev12 - EN-IT-DE
ENGLISH
2. Package content
• Assioma pair of pedals with sensor (1 sensor for Assioma UNO, 2 sensors for Assioma DUO).
• 1 battery charger with EU, US, UK, AU plug adaptors ( IEC Types C, A, G ,I ).
• 2 m USB/micro USB cable (1 cable for Assioma UNO, 2 cables for Assioma DUO).
• Magnetic charging connector (1 connector for Assioma UNO, 2 connectors for Assioma DUO).
• 2 red cleats (6° oat), 1 8 mm hexagonal wrench, 4 washers.
• User manual, Safety instructions, Warranty information.
3. Product description
Assioma is a pedal for racing bicycles with a quick clip system, provided with power
sensor to measure the force applied to the pedal during the pedal stroke.
This pedal includes the function of cadence meter and can calculate the power of a
single leg in real time, sending it to the bike computer.
It is provided with a 50 hour rechargeable battery and is designed to guarantee many
years of use. Therefore, there are no openings with gaskets for the replacement of the
battery.
Assioma is fully sealed (IP67) thanks to its case without openings and all its internal
components are immersed in a special lling resin.
For radio communication, Assioma is compatible with the ANT+ standard and
Bluetooth v4.0 standard, or later version. The use of Bluetooth v4.0 in
smartphones started in 2011 - 2012.
b
c
d
a
4 LEDs, one every 90°
Left pedal (L) or right pedal (R) indication
Connector for battery charging
Sensor
4. Warnings
Please carefully read this manual and the safety instructions before installing
the product. An incorrect installation may lead to accidents and possible
damage to things and/or injury to people.
If you have any doubts about your ability to install the product, we recommend
you to ask for the assistance of a specialized mechanic. An incorrect installation
may cause or result in irreparable damage to the product which shall not be
covered by the warranty. Before starting to ride, check that the force necessary
to release your shoe from the pedal is suitable.
Visit the YouTube channel: Favero Cycling to see the detailed video installation.
https://www.youtube.com/Favero_cycling
5. Quick start
1. Switching on Assioma (Chap. 6).
2. Activating Assioma (Chap. 7).
3. Fixing the pedals to the crank-arms (Chap. 8).
4. Cleat xing, shoe position check and cleat release force adjustment (Chap. 9).
5. Bike computer conguration (Chap. 10).
• Pairing Assioma to the bike computer (Chap. 10.1).
• Conguration of power elds (Chap. 10.2).
• Crank-arm length (Chap. 10.3).
6. Manual zero offset (Chap. 11).
7. Using Assioma for the rst time on road or rollers (Chap. 12).
It is essential to perform a manual zero offset adjustment any time the pedals
are reinstalled, otherwise the data may not be displayed correctly. For maximum
precision, repeat the operation before every use.
6. Switching on Assioma
Assioma will automatically switch on by turning the pedals or starting to ride and will
automatically switch off after 5 minutes of inactivity.
When using for the rst time, Assioma can only be switched on by connecting it
to the battery charger with the supplied cable for a few seconds. If the LEDs do
not blink, charge the battery as indicated in Chap. 13.
For LED behavior read Chap. 18.

Favero ASSIOMA UNO Specifications

General

Power Accuracy	+/- 1%
Battery Life	50 hours
Connectivity	Bluetooth, ANT+
Cleat Compatibility	Look Kéo
Cadence Measurement	Yes
Battery Type	Rechargeable lithium-ion
Water Resistance	IP67
Type	Power Meter
Measurement	Power
Sensor location	Pedal
Charging Time	Approximately 6 hours
