FAY-003
2-12
4. Front panel audio connector (10-pin AAFP)
Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethat
supportsHDAudioaudiostandard.Connectoneendofthefrontpanelaudio
I/Omodulecabletothisconnector.
IMPORTANT:Werecommendthatyouconnectahigh-denitionfrontpanel
audiomoduletothisconnectortoavailofthemotherboard’shigh-denition
audio capability.
5. SATA power connector (4-pin SATA_PWR1)
ThisconnectorisfortheSATApowercable.Thepowercableplugis
designedtotthisconnectorinonlyoneorientation.Findtheproper
orientationandpushdownrmlyuntiltheconnectorcompletelyt.
IMPORTANT:TheSATApowerconnectorsupports1Acurrenttothe
maximum.
FAY-003
FAY-003 Front panel audio connector
AAFP
GND
NC
MIC1-JD
NC
LINEOUT-JD
MIC1_L
MIC1_R
LOUT_R
GND
A_LOUT_L
PIN1
FAY-003
FAY-003 SATA power connector
SATA_PWR1
+5V
GND GND
+12V
Pin1
