FAY-003
2-18
18. M.2 E-key connector (2230_M2E)
ThisconnectorisforM.2E-key(22x30mm)wirelessdevices.
FAY-003
FAY-003 M.2 E-key connector
2230_M2E
NUT_2230_M2E
17. Battery connector (2-pin BATTERY1)
ThisconnectorisforthelithiumCMOSbattery.
FAY-003
FAY-003 Battery connector
+BAT
GND
PIN 1
BATTERY1
