FBD 373 - Page 52

37X INSTALLATION & OPERATION MANUAL
372/373 MODELS
50
Figure 11.2 Mounting Diagram for 373 Dispenser
(4) TAPPED
MOUNTING HOLES
4.31 in.
[109.4]
DRAIN
5.88 in.
[149.4]
DRIP TRAY
18.13 in.
[460.4]
20.03 in.
[508.9]
16.13 in.
[409.4]
25.87 in.
[657.2]
25.14 in.
[638.7]
4.37 in.
[111]
FRONT
