SPECIFICATIONS
General Requirements – All Dispensers
Requirement All Dispensers
Syrup supply pressure 70 - 72 PSIG (4800 – 5000 kPa)
Water supply pressure 70 - 72 PSIG (4800 – 5000 kPa)
CO2 supply pressure 70 - 72 PSIG (4800 – 5000 kPa)
Voltage Single Phase, 200 – 254 VAC
Clearance 3” (76 mm) sides or back, 36” (914 mm) top
Dispenser Specific Requirements
Requirement 772 773 774
Electrical circuit – 60 Hz 20 A 30 A 30 A
Dispenser Specifications
Requirement 772 773 774
Width 17.0” (432 mm) 20.3” (516 mm) 26.0” (660 mm)
Depth 32.3” (820 mm) 32.3” (820 mm) 32.3” (820 mm)
Height 41.4” (1052 mm) 41.4” (1052 mm) 41.4” (1052 mm)
Weight - empty 298 lbs (135 kg) 359 lbs (163 kg) 418 lbs (190 kg)
Weight - operational 321 lbs (146 kg) 393 lbs (178 kg) 464 lbs (210 kg)
Weight - Shipping 338 lbs (153 kg) 404 lbs (183 kg) 468 lbs (212 kg)
