FBD FBD553D - Critical Regulator and Flow Control Settings; 7 Operation of the Dispenser; Operating Electronic Controls

CRITICAL REGULATOR AND FLOW CONTROL SETTINGS
SET ALL PRESSURES USING THE LCD READOUTS ON THE UNIT - NOT
BY THE GAUGES ON THE
REGULATORS!
CO
2 PRIMARY REGULATOR The CO2 Primary Regulator MUST BE SET TO 70-72 PSIG (482.6
TO 496.4 KPa) [bulk tank set at 115-120 PSIG (793.5 - 828.0 KPa)].
CO2 SECONDARY REGULATOR The CO2 Secondary Regulator SHOULD BE SET AT 28-32 PSI
(Secondary Regulator) (193.2 TO 220.8 KPa) STATIC PRESSURE.
The CO2 Secondary Regulator is on the header assembly which is
behind the access panel. This regulator is a “non-vent” regulator. This
means that if you lower the regulator setting, you will need to dispense
drinks (with “Fill” activated) until cylinder begins to refill before the new
setting will register on the gauge.
FLOW CONTROLLERS WATER FLOW MUST BE SET TO PROVIDE A FLOW OF 15
OUNCES IN 10 SECONDS BEFORE ADJUSTING THE BRIX. BRIX
MUST BE SET BETWEEN 13.5 -15. Flow controllers are on the
header assembly. A sample may be taken by fully depressing the
sample valve while "FILL" is in the "OFF" position.
7. OPERATION OF THE DISPENSER
7.1 OPERATING ELECTRONIC CONTROLS
A. The electronic machine controls are designed to provide a logical sequence of operation with a
minimum of written instruction. System operating parameters are selected and set from a
menu.
7
FBD
FWDBACK SELECTCANCEL
OFF
RIGHT SIDE
FILL BEATER
RUN
DEF.
LEFT SIDE
FILL BEATER
RUN
OFFDEF.
CENTER
FILL BEATER
RUN
OFFDEF.
Figure 7.1
B. LEFT, CENTER, and RIGHT Buttons (see Figure 7.1).
1. Each barrel has five (5) active buttons. They are labeled FILL, BEATER, RUN, DEF
(defrost), and OFF.
2. Each button operates a double acting switch. Pressing the button once activates the
process. Pressing the button a second time deactivates the process. Take care not to
double press the buttons when first activating a process.
The RUN button initiates the freeze process. After pressing this button, the
beater motors will run for two minutes before the compressor starts. This
delay eliminates the possibility of "short cycle" damage to the compressor.
Run also maintains the flow of product into the chambers when needed.
The OFF button turns off all the machine's refrigeration and chamber refill
systems. All of the electronic controls are still active.
OFF
RUN
