FBD FBD553D - Flow Diagram;Schematic

15.2 FLOW DIAGRAM/SCHEMATIC
35
FBD 553D, FLOW DIAGRAM
CTRL P14 - LEFT SOLUTION
CTRL P13 - LEFT SYRUP IN
CTRL P17 - H2O IN
CTRL P16 - CO2 REG.
CTRL P15 - CO2 UN-REG.
CTRL P18 - CENTER SYRUP IN
CTRL P19 - CENTER SOLN. OUT
CTRL P22 - RIGHT SYRUP IN
CTRL P23 - RIGHT SOLN. OUT
CONDENSER WATER
12-2606-0001
12-2718-0001
22-0390-0001(12”)
36-2029-0001
SET PRESSURE:
COMPRESSOR HIGH (ACCESS VALVE)
CONDENSER WATER - OUT
CONDENSER WATER - IN
CONDENSER WATER
OUT
IN
250 PSIG
22-0390-0001(50”)
22-0390-0001(40”)
12-2611-0001
34-0103-0002
38-0126-0001
12-2615-0001
12-2610-0001
12-2609-0001
12-2608-0001
22-0389-0001(37”)
12-2146-0002
12-0316-0001
12-0316-0001
12-0316-0001
22-0389-0001(43”)
22-0389-0001(47”)
RIGHT SYRUP - IN
CENTER SYRUP - IN
LEFT SYRUP - IN
H2O - IN
CO2 - IN
30 PSIG
30 PSIG
30 PSIG
RIGHT
BARREL
CENTER
BARREL
LEFT
BARREL
NOTE: PORT LOCATIONS AT
REAR OF EQUIPMENT
SYRUP
RIGHT
SYRUP
CENTER
SYRUP
LEFT
WATER
CO2
12-2150-0001
12-2150-0001
12-2150-0001
