NOTE: Contact FBD Customer Service at
866-323-2777 for questions concerning
compressors and operational issues.
NOTE:
H2O readout will be 15-20
psi higher on the readouts.
Keep regulated pressure at
70-72 psig.
Contact FBD Warranty Dept. at 866-323-2777 before tapping system if unit is under warranty!
(Item 13.20 continued from previous page.)
D. Low 15VDC from Lower Board. D. Check indicator light for 15VDC on
lower power board. Replace lower
board, if necessary.
E. Upper board failure. E. Replace main control (Upper)
board.
REFRIGERATION
13.21 Compressor won’t start. A. Incorrect start procedure. A. Press “Def”, then “Run” to start.
B. Out of CO
2, Syrup or Water. B. Check pressure readouts for 70-72
psig, adjust regulators, if necessary.
C. Run capacitor problem. C. Test run capacitor. Replace, if
necessary.
D. Contactor failure. D. 1. In Manual On/Off, activate
“Compressor.” DO NOT RUN
COMPRESSOR FOR MORE
THAN 10 SECONDS!
If contactor energizes, quickly
check voltage across contactor
T1 and T2 for 220 volt. If no
voltage reading, replace
contactor. “
2. In Manual On/Off, activate
“Compressor.” DO NOT RUN
COMPRESSOR FOR MORE
THAN 10 SECONDS!
If contactor does not energize,
quickly check voltage across
contactor coil terminals for
24VAC. If voltage is present,
replace contactor.
E. Relay board not sending E. Test relay board for 24VAC output
power to contactor coil. and 5VDC input on contactor relay.
Replace relay board, if necessary.
F Lower Board problem. F. Check lower board for +5,
+15, and –15 indicator lights. If
green lights are not energized,
replace board, if necessary.
G. 192 VA Transformer problem. G. Test transformer for 220VAC input
and 24VAC and 12VAC output
(see Section 14, Board
Schematics).
H. Compressor failure, or H. Wait for compressor to cool.
overheated. Check amperage draw on
compressor. Check compressor
wiring and terminals. Replace
compressor,
13.22 Compressor runs long A. Return temperature not A. Verify that Return Temperature
time but won’t freeze dropping. drops below 25°F. Return
down. Temperature should achieve
20-25°F within 7 to 25 minutes of
startup (no drinks dispensed).
B. Airflow through condenser B. Clear condenser of blockage.
is blocked. Dirty filter. Clean air filter.
C. Hot gas valve is activated C. Select “Defrost Sol” in
in Manual On/Off “Manual ON/OFF”; test solenoid,
then turn off.
(Item 13.22 continued on next page.)
32
TROUBLE CAUSE REMEDY
