SPECIFICATIONS FOR THE FBD564 DISPENSER
DIMENSIONS
Width 26.0 inches (660 mm)
Depth 32.3 inches (820 mm)
Height (Standard Countertop Unit) 41.4 inches (1054 mm)
Height (Optional Roll Around Unit/Stand) 75.4 inches (1918 mm)
WEIGHT
Shipping 500 pounds (226.8 kg)
Empty 410 pounds (185.9 kg)
Operational 460 pounds (208.7 kg)
WATER REQUIREMENTS
Minimum flowing pressure 30 psig (207.0 kPag)
Maximum static pressure 70 psig (483.0 kPag)
CARBON DIOXIDE (CO
2) REQUIREMENTS
Minimum pressure 70 psig (482.6 kPag)
Maximum pressure 72 psig (496.4 kPag)
SAFETY PRECAUTIONS
We at FBD are concerned about your safety. Please carefully read the following precautions before working with
the FBD56x units. This will familiarize you with proper equipment handling techniques.
LIFTING
• To avoid personal injury or damage, do not attempt to lift the unit without help. The use of a
mechanical lift is recommended
•• The empty FBD562 unit weighs approximately 318 pounds (144.2 kg).
•• The empty FBD563 unit weighs approximately 365 pounds (166.0 kg).
•• The empty FBD564 unit weighs approximately 410 pounds (185.9 kg).
• Use gloves to protect hands from being injured by the edges of cross bracing if lifting by hand.
• Use proper equipment and lifting techniques when lifting or moving equipment. The unit is top heavy.
Maintain unit in a vertical, upright position when lifting and positioning the unit.
ELECTRICAL
• This unit must be properly electrically grounded to avoid possible fatal electrical shock or serious
injury to the operator. The power cord is provided with a three prong grounded plug. If a three-hole
grounded electrical outlet is not available, use an approved method to ground the unit. Only qualified
electricians should perform this task and the work performed should meet all applicable codes.
• Always disconnect electrical power to the unit to prevent personal injury before attempting any
internal maintenance. Only qualified personnel should service internal components of electrical
wiring.
CARBON DIOXIDE (CO2)
• CO
2 (carbon dioxide) displaces oxygen. Strict attention must be observed in the prevention of CO2
gas leaks in the entire CO2 and soft drink system. If a CO2 gas leak is suspected, immediately
ventilate the contaminated area before attempting to repair the leak. Personnel exposed to high
concentrations of CO2 gas will experience tremors which are followed rapidly by loss of
consciousness and suffocation.
• To avoid personal injury and/or property damage, always secure CO
2 cylinders in an upright
position with a safety chain to prevent cylinders from falling over. Should the valve become accidentally
damaged or broken off, a CO2 cylinder can cause serious personal injury.
