APPENDIX C - APPROVAL INFORMATION
Fluid Components International LLC 83
Annex 1
Annex 1 to Certificate of Conformity IECEx DEK 14.0080X, issue 0
Annex 1 to IECEx TR NL/DEK/ExTR14.0088/00
Annex 1 to EU Type Examination Certificate KEMA 02ATEX2166 X, issue 4
Page 1 of 5
Form 124
Version 2 (2013-07)
DEKRA Certification B.V. Meander 1051, 6825 MJ Arnhem P.O. Box 5185, 6802 ED Arnhem The Netherlands
T +31 88 9683000 F +31 88 9683100 www.dekra-certification.com Registered Arnhem 09085396
Note 1: in this document [.] is used as decimal separator.
Type designation Flow, Level or Temperature FlexSwitch Series FLT93
The Flow, Level or Temperature FlexSwitch Series FLT93 are divided into three styles:
Insertion style: FLT93S, FLT93F and FLT93C
Basic insertion style: FLT93B
In-line style: FLT93L
Model decoding FLT93S, FLT93F and FLT93C series Insertion style
FLT93
S
3
B
1
A
custom
B
4
custom
0
custom
I
II
III
IV
V till VII
VIII
IX
X till XII
XIII
XIV till XV
Pos.
Explanation
Value
Explanation
Type of sensor
FLT93S
FTL93F
FLT93C
Insertion style with larger OD thermowells (S=Std response time)
Insertion style with small OD thermowells (F=Fast response time)
Insertion style with larger OD thermowells Sanitary version
I.
Agency
Approval
3
6
ATEX approved
IECEx approved
II.
Customer
tagplate
B 316L stainless steel
III.
Process
temperature
1
2
-40 °C to + 177 °C
-40 °C to + 260 °C (only with remote enclosure, pos. XIII ≠ 0)
(Refer to thermal data in this Annex.)
IV.
Material of
sensor
A
B
C
D
E
316 (L) stainless steel (only for S and F type of sensor)
316 (L) stainless steel electro polished
Hastelloy C276 (only for S and F type of sensor)
Monel 400 (only for S and F type of sensor)
Titanium grade 2 (only for S type of sensor)
V till
VII
Process
connections,
size of process
connection and
insertion length
custom
Process connection & size not relevant for Ex type of protection
Insertion length till 3 050 mm. Material of flange stainless steel,
carbon steel or same as sensor.
VIII.
Local enclosure
(local = at
sensor)
B
C
D
E
Pigtail version; sensor with cable pigtail
(only when I=3 and XIII = B, G or C)
Aluminium Ex d enclosure with single cable entry
Aluminium Ex d enclosure with dual cable entry
Stainless steel Ex d enclosure with single cable entry
IX.
Configuration
(type of
electronics)
4
5
Standard version of electronics
Electronic with hermitically sealed relays contacts
X till
XII
Application
alarm point 1, 2,
calibrations
custom Not relevant for Ex type of protection
XIII.
Remote
enclosure
0
B
G
C
None (the electronics is mounted inside local enclosure of pos. VIII.)
Aluminum Ex d enclosure with single cable entries
Aluminum Ex d enclosure with dual cable entries
Stainless steel Ex d enclosure with single cable entry
