FCI FLT93B User Manual

FLT
®
Series FlexSwitch
TM
APPENDIX C - APPROVAL INFORMATION
Fluid Components International LLC 85
Annex 1 to Certificate of Conformity IECEx DEK 14.0080X, issue 0
Annex 1 to IECEx TR NL/DEK/ExTR14.0088/00
Annex 1 to EU Type Examination Certificate KEMA 02ATEX2166 X, issue 4
Page 3 of 5
Model decoding FLT93L series In-line style
FLT93L
3
B
1
custom
1
custom
B
4
custom
0
custom
I
II
III
IV
V
VI
VII
VIII
IX till XI
XII
XIII till XIV
Pos.
Explanation
Value
Explanation
Type of sensor
FLT93L
In-line version (thermowells placed inside pipe spoolpiece)
I.
Agency
Approval
3
6
ATEX approved
IECEx approved
II.
Customer
tagplate
B 316L stainless steel
III.
Process
temperature
1
2
-40 °C to + 177 °C
-40 °C to + 260 °C (only with remote enclosure, pos. XII ≠ 0)
(Refer to thermal data in this Annex.)
IV.
Sensor
configuration
custom Not relevant for Ex type of protection
V.
Material of
sensor
1
2
3
4
316 (L) stainless steel
Hastelloy C276
Monel 400
Titanium grade 2
VI.
Process
connections
custom
Process connection not relevant for Ex type of protection. Material of
flange stainless steel, carbon steel or same as sensor.
VII.
Local enclosure
(local = at
sensor)
B
C
D
E
Sensor with cable pigtail: requires Ex d adapter and cable gland (only
when I = 3 and XII = B, G, C)
Aluminium Ex d enclosure with single cable entry
Aluminium Ex d enclosure with dual cable entry
Stainless steel Ex d enclosure with single cable entry
VIII.
Configuration
(type of
electronics)
4
5
Standard version of electronics
Electronic with hermitically sealed relays contacts
IX till
XI
Application
alarm point 1, 2,
calibrations
custom Not relevant for Ex type of protection
XII.
Remote
enclosure
0
B
G
C
None (the electronics is mounted inside local enclosure of pos. VII.)
Aluminum Ex d enclosure with single cable entries
Aluminum Ex d enclosure with dual cable entries
Stainless steel Ex d enclosure with single cable entry
XIII
till
XIV
Cable material
& length
custom PVC or Teflon cable, length not relevant of Ex type of protection
Electrical data:
Power supply : 115 Vac (± 15) 50/60 Hz; 13 watts, 100 mA max.
: 230 Vac (± 10) 50/60 Hz; 14 watts, 50 mA max.
: 24 Vac (18 V to 26 Vac) 50/60 Hz; 7 watts, 230 mA max.
: 24 Vdc (21 V to 30 Vdc); 7 watts, 230 mA max.
Relay Rating : 115 Vac / 240 Vac or 24 Vdc, 6A
Sensing Element Heater Power : 3.0 W max.
