FDP CFN - 3.5.1 LED FOR SHARED FUNCTIONS, 3.5.2 LED OF THE ZONE, AND 3.5.3 BUTTON DESCRIPTIONS

Page 12 of 35
Rev. 1.03
3.5.1 Led for shared functions
Listed below there are the description of the corresponding main leds:
LED Colour Description
POWER SUPPLY Green
Normally on, it indicates if the control panel is supplied.
Slow flashing it indicates if the 230Vac power is missing. After about 20
minutes from the 230Vac is missing, the control panel goes to fault.
Off when the control panel is not supplied.
ALARM Red
Normally off.
Slow flashing it indicates the alarm status.
Fixed light it indicates that the alarm is silenced.
PREALARM Red
Normally off.
Slow flashing it indicates the pre-alarm status.
Fixed light it indicates that the pre-alarm is silenced.
FAULT Yellow
Normally off.
Slow flashing it indicates the fault status.
Fixed light it indicates that the fault relay output is placed to out of service.
POWER FAULT Yellow
Normally off.
Slow flashing it indicates that the 230Vac is missing.
Fixed light it indicates the battery fault.
SYSTEM FAULT Yellow
Normally off.
Fixed light it indicates the control panel fault.
TEST Yellow
Normally off.
Fast flashing when the control panel is in the zone test status.
OUT OF SERVICE Yellow
Normally off.
Fixed light when at last a zone or a output (siren or relay) is in out of service.
SIREN Yellow
Normally off.
Slow flashing it indicates the fault status of the siren output (open circuit or
short circuit).
Fast flashing it indicates that a siren output is active.
Fixed light it indicates that the alarm/pre-alarm outputs are in out of service.
LEVEL Yellow
Normally off.
Fixed light it indicates that the level 2 is active.
Slow flashing it indicates that the level 3 is active.
Fast flashing it indicates that the level access is active.
3.5.2 Led of the zone
Listed below there are the description of the corresponding leds for the zones:
LED Colour Description
ZONE ALARM Red
Normally off.
Fixed light it indicates the alarm/pre-alarm of the zone.
Fast flashing it indicates the alarm status of the zone causes from a manual
alarm.
FAULT – OOS/TEST Yellow
Normally off.
Fixed light it indicates that the zone is to out of service.
Slow flashing it indicates the fault status of the zone.
Fast flashing it indicates the test status of the zone.
3.5.3 Button descriptions
Listed below there are the description of the corresponding button commands:
Button Description
SILENT
Level 1: it permits the silent of the internal buzzer.
Level 2: it permits the silent of the internal buzzer and siren and relay outputs.
RESET
Level 2: it permits the reset of the alarms and faults signalling (led, relay and siren
outputs).
Level 3: it permits the reset of the alarms and faults signalling, and the default setting
