FDP CFN - PART 9 TECHNICAL CHARACTERISTICS; GENERAL, ZONE, AND SIREN OUTPUT SPECIFICATIONS

Page 27 of 35
Rev. 1.03
GENERAL
Case size: Metal case: base x depth x height 351x95x292mm.
Protection index: IP40.
Weight: Metal case: 3.5Kg without battery.
Operating temperature: -5° / +40°C.
Relative humidity: 95% maximum.
Power supply: 230Vac ±10/-15%, 50Hz.
Max absorption: 50VA.
Power supply fuse: T 500mA L 250V.
Transformer block output: 34Vac.
24V aux output: 21,5Vdc to 28Vdc.
WARNING: the 24V aux is protected from a fuse, but it is not supervised. The
control panel does not control the fuse status.
24V aux fuse: F 315mA L 250V.
Battery charger: 27.6Vdc at 20°C.
Battery: Lead sealed at Pb 24V – 7,2Ah.
Battery fuse: T 2A L 250V.
ZONE
Zones: Control panels from 2, 4 or 6 zones.
Max. number of detectors: 20.
End of line resistor:
3.9KΩ 1/2W.
Alarm current: 25mA.
Alarm resitor:
220Ω 2W.
Prealarm resistor:
1KΩ 1W.
SIREN OUTPUT
Siren output: 2 supervisory siren outputs. Short and open circuit control.
Output 1: alarm.
Output 2: pre-alarm.
Max. current: 250mA.
End of line resistor:
10KΩ 1/4W.
