FDP CFN - PART 8 SIREN OUTPUT PROGRAMMING; 8.1 MANUAL ACTIVATION, 8.2 SIREN OUTPUT SILENT, AND 8.3 OUTPUT DELAY

Page 25 of 35
Rev. 1.03
The control panel has two supervisory siren outputs (alarm and pre-alarm outputs). The control
is at polarity inversion with a minimum output voltage, this voltage is sufficient to control the
line status. To do this, it is necessary that for every output it is installed an and of line resistor.
NOTE: the outputs are the current limited: max 250mA.
A superior current absorption (caused from a short circuit) causes the activations of the power
surge controller. Of consequence the zone cables have null voltage and the fault is signalled.
8.1 MANUAL ACTIVATION OUTPUT
Procedure:
• Access at level 2.
• Push <SIREN> button. The led <SIREN> flashes with quick intermittence.
• To select the output:
o To push zone <1> button for output 1.
o To push zone <2> button for output 2.
• To finish this test procedure, to push <LEVEL> button.
8.2 SIREN OUTPUT SILENT
If the control panel is in alarm status and the user wants to silence all siren outputs, without to
lose the information about alarmed zone (case which the <RESET> button is pressed), it is
necessary to do the silence procedure of 2
nd
level (see chapter 6.6).
8.3 OUTPUT DELAY
It is possible to set a siren output delay (alarm and pre-alarm outputs).
Procedure:
• Access at level 3.
• Push <SIREN> button. The led <SIREN> flashes with T=0.5. At this time the <ZONE
ALARM> and <FAULT – OOS/TEST> leds attributed to 1 and 2 zone, it gives the delay
information on 1 and 2 outputs.
• To modify the 1 zone delay the user must use <1> button and for the 2 zone the <2>
button.
Output delay
Led
<ZONE ALARM>
Led
<FAULT – OOS/TEST>
0s Off Off
30s Off On
60s On Off
120s on On
• To confirm the modification to push <SIREN> button.
PART 8
SIREN OUTPUT PROGRAMMING
