The <SILENCE> led is on until:
1) a new status change of the control panel that requires the buzzer activations;
2) there is an automatic reset of the fault which has generated the buzzer activation;
3) the reset procedure is launched.
6.6 SILENCE (2
nd
LEVEL)
Second level silence permits to silent the internal buzzer and to restore the siren relay outputs.
Procedure:
• Access at level 2.
• Push <SILENCE> button.
The <SILENCE> led is on until:
1) a new status change of the control panel that it requires the buzzer activations;
2) there is an automatic reset of the fault which has generated the buzzer activation;
3) the reset procedure is launched.
6.7 RESET
The control panel reset permits to restore the normal status of the control panel.
The reset command does:
1) restoration of the siren and relay outputs;
2) silent mode of the internal buzzer;
3) restoration of all zones (during the reset, all zone outputs are set to 0V);
4) restoration of all fault and alarm signals.
Procedure:
• Access at level 2.
• Push <RESET> button.
The reset employs approximately 10s; during this procedure, all leds are on. The opearation
terminates with the sound of a double “beep”.
6.8 DEFAULT SETTING RESTORATION
This procedure has same functions of reset (chapter 6.7) and besides it permits to set the
control panel with factory default values (see chapter 4.1).
Procedure:
• Access at level 3.
• Push <RESET> button.
The reset employs approximately 10s; during this procedure, all leds are on(with the exception
of the one that indicates the system fault).
