Page 22 of 35
Rev. 1.03
PART 7
ZONE PROGRAMMING
For every zones it is possible to define until a maximum of 32 detector points; they are divided
in this mode:
ü max 20: active detectors that are supplied from zone cables (about 50µA for the normal
current);
ü remaining point to achieve the maximum number allowed: passive points (supplying 0A)
such as buttons, smoke linear barriers, alarm devices with relay output,
Quite apart if the user uses all zones, for every zones must to be installed the end of line
resistor. If the zone is used, the resistor must to be placed at end line. If a zone is not used the
resistor must to be installed to zone clips of the motherboard.
The resistor absence or the incorrect value generate a fault zone signal.
7.1 OUT OF SERVICE OF ZONE
This procedure permits to disable the alarm and fault controls.
The control panel indicates the out of service of zone with <OUT OF SERVICE> and <FAULT
OOS/TEST> leds of the interested zone. The <OUT OF SERVICE> led is on as long as
there is at least a zone in out of service.
NOTE: a zone in out of service stands to have a 24Vdc as normal zone. If the user wants
to do maintenance at a zone, it is necessary to put it to out of service and to disconnect
the cables from motherboard clips.
Procedure:
Access at level 2.
Push <OUT OF SERVICE> button. The led <OUT OF SERVICE> quick flashes.
To modify the out of service status of the zones with the <ZONE BUTTON>.
o Zone led is on: out of service enabled.
o Zone led is off: out of service disabled.
To confirm the modification to push < OUT OF SERVICE > button.
To interrupt the procedure and return to level 1 without having applied any changes, press the
<LEVEL> button.
7.2 ZONE TEST
The zone test permits to verify the correct functioning of detectors or zone in the case which of
an alarm. In this status, the control panel does not activate the siren and relay outputs if a zone
in test modality goes to alarm or fault status.
Procedure:
Access at level 3.
Push <TEST> button. The led <TEST> flashes with quick intermittence.
To put or remove the test function of a zone, it is necessary to push <ZONE BUTTON>.
The zone led start to flash with quick intermittence to indicate the test status.
