6 Technical Data
ID ISC.LRM2500-B
Mechanical Data
 Dimensions ( W x H x D )
160 mm x 120 mm x 46 mm
(6.29 inch x 4.72 inch x 1.81 inch)
 Weight
approx.. 0,6 kg (1.32 lb)
Electrical Data
 Supply Voltage
24 V  15 %
Noise Ripple : max. 150 mV
 Power Consumption
Typical 35 VA / maximum 47VA (depending on ext.
output circuitry)
 Operating Frequency
13,56 MHz
 Transmit Power
2W – 12 W
(250 mW Step - Software)
 Modulation
10% - 30%
(Software configurable)
 Antenna Connection
SMA Jack (50)
 DC Supply at Antenna Con-
nector
8 V (max. 150mA)
 Diagnostic Options
internal VSWR-Meter
internal temperature monitoring
 Outputs
– 2 Optocoupler
– 3 Relay ( 3 x NO)
24 V / 30 mA (optional usable as Data Clock IF)
24 V / 1 A
 Inputs
– 3 Optocoupler
5- 24 V / 20 mA (See chapter: 3.6)
 Interfaces
 RS232
 RS485
 USB – Interface (HID)
 Ethernet (TCP/IP)
 Data Clock
