3.11.3 USB – Interface X4 (Host Communication, HID)
The USB socket on the board is terminal X4. The pinout is standardized. The data rate is reduced
to 12 Mbit (USB full speed). A standard USB-cable can be used.
Note:
The length of the USB-cable can be a max. of 5m (20 inch). It is not allowed to use longer
cables.
X4
Figure 22: USB-Interface for host communication
