15
Edgebander
G 330 / G 360 / G 380
The working areas of this machine comply to DGUV
Information 209-044 and are classed as dust reduced.
The maximum concentration level of 2 mg/m³ of inhala-
ble dust in the air will not be exceeded.
This only applies if the conditions that are specified in
the section >Extraction< are adhered to.
See chapter entitled >Setup and installation<
4.3.3 End trimming saw unit
4.3.4 Radius trimming unit
4.3.5 Buffing unit
4.4 Particle emission
Technical specifications
Speed 9.000 rpm
Motor 0,18 kW
Tooth width H 3,2
Outer diameter of the standard blade 80 mm
Bore 20 mm
Number of teeth Z 16
Speed 12.000 rpm
Motor 0,22 kW
Outer diameter of the spindle moulder 77 mm
Bore 20 mm
Spindle moulder width H 16
Number of teeth or blades Z 4
Rotation speed of the buffing pads: Motor power 0,9 kW 1400 rpm
Buffing pad dimensions (No. 4) 125 mm x 20 mm x St. 12,5
