48
!
!
Edgebander
G 330 / G 360 / G 380
Respect the general safety rules.
See chapter entitled >10.1 Safety instructions<
1. Switch the machine on and let it warm up to its ope-
rating temperature.
2. Switch the machine off and ensure that it cannot be
switched on again
3. The following service must be performed at the
prescribed intervals.
• Lubrication - End trimming unit
• Lubricating the glue roller bearing
• Cleaning and lubrication - Chain feeder
• Check the chain tension/Set
4. Reset meter >LUB<
OFF key - press and hold (approx. 10 seconds)
Maintenance/Service
10.3 Cleaning and lubrication
Attention! Risk of material damage!
The following maintenance has to be carried out according to the instructed time intervals!
Fig. 10-2: Electrical control panel
! OFF key
Note: The following value appears in the display >LUB<. (Display of the maintenance intervals)
Lubricate the machine after every 24 to 32 operating hours of intensive use.
Use regular machine grease.
