58
"
!
OIL
Edgebander
G 330 / G 360 / G 380
Note: Only sharpen the slanted side of the knife blade.
Fig. 10-19: Replace and sharpen the knife blade
Fig. 10-18: Replace and sharpen the knife blade
Respect the general safety rules.
See chapter entitled >10.1 Safety instructions<
Wet the trimming knife and its guidings with
silicone-free oil.
When lubricating with silicone-free oils, completely dry
the cutting shears with a cloth. Silicone-free lubricants
can lower the adhesive properties of the glue.
To replace or sharpen a shear knife which cuts from the
roll, proceed as follows:
• Switch the machine off at the main switch.
Pinch off the shaper cutter compressed air supply.
• Manually move the cutter knife to the front.
• Loosen the fixing screw as indicated with the Alan
key supplied with standard equipment.
• Shear knife: regrind or replace
! Fixing screws blade
" Shear knife
10.9 Guillotine unit - Replacing, sharpening and lubricating the blades
Maintenance/Service
