Felder G 360 - 8.4 Massivholzkanten > 4 mm

31
#
"
!
Edgebander
G 330 / G 360 / G 380
8.4 Solid wood edging > 4 mm
Remove the rollers in the edge guide.
Dismantle the edge guide.
Set the first roller of the edge guide to double the
edge thickness.
! Rollers edge feed
" Edge guide
§ First roller
Inspecting and adjusting settings
Fig. 8-3.2: Edge tape feeding
Fig. 8-3.3: Edge tape feeding
