INSTRUCTION MANUAL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
............................................PresetEditFXMode
35
+ "
%
% %
Description
Stereo flange effects with sine-wave or triangle-wave delay modulation.
Just as in the chorus effects, the sine-wave flange tends to have more
“swirl,” while the triangle-wave version is more transparent.
Adjustable parameters
Flange Output Level. Adjusts the wet/dry signal ratio. Select between
1.0 for 0% wet (no effect) and 10.0 for a 50% mix.
$
Flange Rate (Hz). Range: from 0.08 Hz to 10 Hz. Adjusts the rate of
the flange effect. The increment of change gradually increases from
0.01 Hz for the slowest rate to 0.08 Hz for the fastest rate. Remember
that the TAP button can always be used to key in the flange rate by
feel– two TAPs set the time it takes for the flange LFOs to go through
one cycle. Remember that although this is a stereo flange, both of the
flange voices move at the same rate.
"
Flange Depth. Adjusts the amount of Doppler shift and how apparent
the effect sounds. Select between 1.0 for no apparent effect and 10.0
for maximum effect.
#
Flange Feedback. Adjusts how much signal from the flange taps is
recycled back to the input. Select between 1.0 for minimum levels that
result in chorus-like sounds and 10.0 for maximum flanging.
%
SineFlange/Tri Flange Phase. Adjusts the phase relationship
between the two flange Low Frequency Oscillators. Select 1.0 and the
two voices of the flange are in phase, which creates the deepest
flange. Select 10.0 and the LFOs are out-of-phase and the maximum
stereo effect is achieved.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
! "
# #
Description
A tremolo with the sound of a vintage Blackface amp.
Adjustable parameters
Tremolo Output Level. Adjusts the wet/dry signal ratio. Select
between 1.0 for 0% wet (no effect) and 10.0 for 100% wet (all effect).
$
Tremolo Rate (Hz). Range: 0.08 Hz to 10 Hz. Adjusts the rate of the
tremolo effect. Select between 0.08 for a slow sweeping rate and 10 for
a fast rate. The increment of change gradually increases from 0.01 Hz
for the slowest rate to 0.08 Hz for the fastest rate. Remember that the
TAP button can always be used to key in the tremolo rate by feel– two
TAPs set the time it takes for the LFO to go through one cycle.
"
Tremolo Depth. Adjusts how deeply the tremolo drops the volume.
Select 1.0 for minimum depth and 10.0 for maximum depth.
