1.3 Specificat
ions
1.3.1 Specifications
Specifications and design are subject to change wit
hout notice and without liability therefore.
1.3.1.1 Dimensions and weights
Baler
Length
With roller bale chute in the up position 9830 mm (387 in)
Height
With the hand rail down 3022 mm (119 in)
With the hand rail up 3375 mm (133 in)
Width
Tandem axle with standard 620/50R-22.5 wheels 2990 mm (117.7 in)
Tandem axle with 620/55R-26.5 wheels 2990 mm (117.7 in)
Tandem axle with 710/50R-26.5 wheels 3190 mm (125.6 in)
Minimum, tandem axle with no tires 2720 mm (107 in)
Weight (approximate)
Tandem axle, empty 13400 kg (29500 lb)
Tongue weight - tandem axle, empty 2040 kg (4500 lb)
Bale chamber
Height 875 mm (34.4 in)
Width 1200 mm (47.2 in)
Adjustable bale length Up to 3200 mm (126 in)
1.3.1.2 Drive system specificat
ions
Power tak
e-o (PTO)
PTO speed 1000 rpm
Type 3, Category 6-7 IDL ISO (ASABE) Type 3, 45 mm (1-3/4 in), 20
tooth
Intermediate shaft ISO (ASABE) Category 6-7
Clutch Overrunning
Flywheel
Rotation direction Counterclockwise - look from the front to
the rear
Speed 1500 rpm
Diameter 990 mm (39 in)
Width 250 mm (9.8 in)
4
[V]
GUID-8DC81A41-246E-458F-8178-FF766D40A78D [V1]
GUID-704B0DCE-463F-4E64-A46D-4F1733686704 [V2]
GUID-682477C8-65CE-4C8B-86F9-A7B7C947F4F7 [V2]
1. General
1-22 Large Square B
aler
79037317B
