FENDT 1290 UD User Manual

Weight 500 kg (1100 lb)
Flywheel brake Manual lever
Clutches Slip
Protection Reset clutch on flywheel
Main gearbox
Type Enclosed double reduction
Gears Spiral bevel gear and spur gear
Bearings Tapered roller and ball bearings
Lubrication Oil bath
Temperature sensor alarm setting 100 °C (212 °F)
Pedestal gearbox
Type Enclosed step up
Lubrication Oil bath
Fan stops operation 79 °C (174.2 °F)
Fan starts to operate 82 °C (179.6 °F)
Temperature sensor alarm setting 100 °C (212 °F)
1.3.1.3 Shearbolt specificat
ions
Stuer/knotter/needles
Shearbolt and nut M16 x 2 x 80.8
Shearbolt torque 225 Nm (165 lbf ft)
1.3.1.4 Hydraulic specificat
ions
Bale density system
Type of valve system Pressure compensating, open center
Pump type Gear pump
Pump location On the pedestal gearbox
System pressure relief valve setting 203 bar (2950 psi)
Temperature sensor alarm setting 100 degree C (212 degrees F)
Knotter blower
Pump type Gear pump
Pump location On the bale density pump
1.3.1.5 Pickup specificat
ions
Width overall, with pickup wheels 2980 mm (117 in)
Width overall, without pickup wheels 2650 mm (104 in)
Width inside 2250 mm (88.6 in)
Height control 2 pickup wheels
4
GUID-7EE85383-FF92-44A6-9AEF-C2D1EB9D6E04 [V2]
GUID-AC0E2C90-C3C2-4234-9FF3-C830F072D68E [V2]
GUID-FADF9C8F-0608-49CA-B17B-CD6EB333045A [V2]
1. General
Large Square Baler 1
-23
79037317B
