FENDT 1290 UD User Manual

(5) Parking brake
(6) Right bale density cylinder
(7) Right tail lamp and turn signal lamp
(8) Load cell for bale weight - right side
(9) Hand rail
(10) Right beacon lamp
(11) Knotter blower cover
(12) Knotter shield
(13) Front shield
(14) Front shield latch
(15) Cooling fan for onboard hydraulic system (on
left side)
(16) Electrical harness - ISObus™
(17) Hydraulic hoses - hydraulic jack (optional)
(18) Electrical harness - road lamps
(19) Hydraulic hose - steering lock
(20) Hydraulic hose - hydraulic brakes (optional)
(21) Hydraulic hoses - pickup and packer
(22) Safety chain
(23) Implement drivelive
(24) Tongue
(25) Pedestal gearbox
(26) Jack - hydraulic (optional)
(27) Hydraulic fluid reserv
oir for onboard hydraulic
system
(28) Windguard chain and spring support
(29) Roller windguard
(30) Pickup
(31) Pickup wheel
(32) Pickup chain cover - right side
(33) Right side shield
(34) Right side shield latch
(35) Right side shield handle
(36) Tires, wheels, and axles
(37) Roller bale chute
1.5.3 Inner view - left side
GUID-6C586CB8-8656-4E22-8209-60D87E34C93E-high.jpg [High]
Fig. 42
(1) Implement driveline
(2) Pedestal gearbox
(3) Overrunning clutch yoke
(4) Hydraulic fluid reserv
oir for onboard hydraulic
system
(5) Slip and reset clutch
(6) Flywheel
(7) Main gearbox
(8) Main drive sprocket
(9) Mounting plate for main gearbox
(10) Stuer clutch and stuer drive sprocket
(11) Needle protection linkage
(12) Knotter blower
(13) Knotter/needle clutch
(14) Needles
(15) Stuer fingers
(16) Stuer sensor door
(17) Stuer trip linkage
(18) Flywheel brake lever
(19) Main driveline
GUID-3F815983-4BC4-4097-B584-FCAA440426C1 [V1]
1. General
Large Square Baler 1
-35
79037317B
