1.3.1.9 Twine specificat
ions
Type High quality split film polyprop
ylene
twine for low and middle force loads.
AGCO® brand twine for high force loads.
Storage capacity 36 balls
Minimum knot strength
Plunger load set below 465 kN Twine rated for 2000 N to 2450 N (450
lbf to 551 lbf)
Plunger load set from 465 kN to 600 kN Twine rated for 2891 N to 3336 N (650 lbf
to 750 lbf)
Plunger load set above 600 kN AGCO® brand twine rated at 3336 N and
above (750 lbf and above)
Twine not made for use in this machine will not work correctly. Low quality, incorrect type, or incorrect
strengt
h twine can cause knotter malfunction, and knotter and twine failures.
Crop with more spring-back will have to have stronger twine.
1.3.1.10 Knotter and needle specifications
Knotter quantity 6
Knotter type double knot
Knotter spacing 176 mm (6.9 in)
Needle quantity 6
Protection Shearbolt on the main drive sprocket
Knotter/needle lockout Switch by the left rear corner of the bale
chamber
Needle protection linkage Automatic, link to needle carriage
1.3.1.11 Bale chamber tension specificat
ions
Control Manual or automatic control hydraulics
Actuation Spool type solenoid valve
System supply Open center on board hydraulics
1.3.1.12 Ejector specificat
ions
Number of teeth 12
Slide type Ball bearing rollers
Power Hydraulic cylinder
Cylinder diameter 64 mm (2.5 in)
Cylinder stroke 914 mm (36 in)
Valve Enable valve/control valve
Operation Switch and teeth selection at rear
GUID-2E186457-8B05-4204-AA26-D36C508F73BE [V1]
GUID-CD6992A9-182A-4431-B8CC-FD25225C6DBD [V1]
GUID-708B34DF-55F2-48EB-BD44-FAB8DCCD686D [V2]
GUID-17E4B1BA-CC96-4640-9293-7D1635E9DFF2 [V1]
1. General
Large Square Baler 1
-25
79037317B
