1.3.1.13 Roller bale chute specificat
ions
Length 2000 mm (79 in)
Number of rolls 5
Roll diameter 127 mm (5 in)
Lift mechanism Hydraulic cylinder
1.3.1.14 Lamp specificat
ions
Field lamps - knotter flag lamp, left side field lamp and right
side field lamp
3 LED
Service lamps - knotter maintenance lamp, ladder lamp, needle
lamp, twine bo
x lamps
5 LED: twine boxes, needles, knotters,
steps
Road lamps 2 LED tail, flashing, and turn lamps
Beacon lamps 2 beacon lamps
NOTE: Field lamps include al
l lamps that are not road lamps or beacon lamps.
1.3.1.15 Knotter lubrication pump specifications
1290
Power System SBC (Square Baler Controller) system
Enclosure rating IP 6K9K - protected from water sprayed in all
d
irections
Maximum operating pressure 20 bars (290 psi)
Knotter pump pressure relief valve 100 bars (1450 psi)
Temperature range -25 to +70 degree C (-13 to + 158 degree F)
Pump output 2.8 cu cm/min (0.1 fl oz/min)
Outlet connection 1/8 inch NPT (female)
Number of lubrication points (6 points per knotter) 36
1.3.1.16 Chain lubrication pump specificat
ions
Power system square baler controller (SBC) system
Maximum operating pressure 30 bars (435 psi)
Pump output 25 ml/min (0.8 fl oz/min)
Outlet connection 1/8 inch NPT
1.3.1.17 Lubricants and capacities
Gearbox, main
Lubricant ISO 320 synthetic extreme pressure
hea
vy duty gear lubricant
(Shell Omala S4 GX 320)
Quantity 27.7 L (29.3 qt)
4
GUID-A98F93A4-E5F7-4B1A-8413-02FA02ACEA81 [V1]
GUID-F02B6760-5C5A-4B9D-976E-3FE3FFA919D8 [V1]
GUID-E3F96757-CA70-4C04-9281-4A747F7F2D60 [V1]
GUID-D0755844-85C1-4C38-82C1-E8936610E7BE [V1]
GUID-E1C51D98-73B4-4168-BB06-E9F9901DFC83 [V1]
1. General
1-26 Large Square B
aler
79037317B
