FENDT 1290 UD User Manual

Lift mechanism Two single acting hydraulic cylinders
Flotation Two extension springs
Tine bar protection Slip and overrunning clutches on right-
hand side
Drive chain RC60 roller chain
Tine bar drive Cam and drive arms on right-hand and
left-hand sides of pickup
Tine bar bearings Sealed, grease lubricated ball bearings
Number of tine bars 5
Tine spacing, tine to tine 66 mm (2.6 in)
Overall width outside tine to outside tine 2046 mm (80.6 in)
Total number of tines 80 double tines
1.3.1.6 Packer specificat
ions
Drive protection Slip clutch
Drive chain 100H
Mechanism 6 bolt on packer control arms and 6 bolt
on hardened pack
er fingers
Crank and bearings assembly 4 crank arms, 6 ball bearings in 3 crank
hubs
1.3.1.7 St
uer specifications
Stuer latch lock Manual lever, direct acting
Protection Shearbolt on the main drive sprocket
Chain 100 HS
Number of st
uer fingers 6
Clutch engage Automatic stuer sensor door engages
stuer clutch
1.3.1.8 Plunger specificat
ions
Length of stroke 740 mm (29.1 in)
Speed (strokes/min) 50
Front and rear rollers and bearings 4 rollers with tapered roller bearings
Side rollers and bearings 2 rollers with sealed ball bearings
Connecting rod bearings 4 spherical roller bearings
Connecting rod length without bearings 996 mm (39.2 in)
GUID-4553BE9F-D950-479B-B3B2-1618ED8315FA [V2]
GUID-14FA70F0-151D-49DA-A22C-CEF45C23FD59 [V2]
GUID-8D81030B-2979-420D-AB34-11F766CAEC97 [V2]
1. General
1-24 Large Square B
aler
79037317B
