PROGRAMMING MENU
Program Options
Options inputs logics
NC Close If enabled, Close signal is activated without voltage (Normally closed contact).
NC Open If enabled, Open signal is activated without voltage (Normally closed contact).
NC Slow Close If enabled, Slow close signal is activated without voltage (Normally closed contact).
NC Reopen If enabled, Reopen signal is activated without voltage (Normally closed contact).
NC Curtain If enabled, Light Curtain is activated without voltage (Normally closed contact).
NC Floor level If enabled, Floor level is activated without voltage (Normally closed contact).
NC Close position If enabled, Close position is activated without voltage (Normally closed contact).
Program Options
Options functions
Eco Mode No The VF always applies the Close Maintenance Torque.
Control The VF stops applying the Close Maintenance Torque if the closing signal is removed.
Close delay The VF stops applying the Close Maintenance Torque after a programmable time delay
(Eco delay) since the door is closed.
Control delay The VF stops applying the Close Maintenance Torque if the closing signal is removed
and the programmable time delay has nished (Eco delay).
CDL Electronic
If enabled, After a power failure the VF opens the Car Door Lock if the cabin is on the oor level.
Security Device None None security device installed.
Curtain Light Curtain installed. The blocked signal must be connected to Re-open input and the
failure signal must be connected to Light Curtain input.
Barrier timer If enabled, an intelligent timer is used in case of photocell or curtain permanent obstruction. The protection
is disabled after 2 minutes permanently blocked. If a physical obstruction happens during the next closing
movement, the VF reopens and wait 4 minutes before closing again. If another physical obstruction happens
during the next closing, the VF reopens and wait 10 minutes before closing again. Finally, if another physical
obstruction happens during the next closing, the VF reopens and remains always open. The photocell or
curtain is enabled again when there is not any physical obstruction during the closing movement.
Temperature
measurement
If enabled, the VF7 measure the motor temperature.
Temperature
Protection
Drive When the overheating alarm is active the circuit does not allow the door closing.
Elevator When the overheating alarm is active the elevator does not allow the door closing.
Energy limit The circuit limits the maximum velocity in order not to exceed a kinetic energy of 10 joules.
Obstruction Backstep If enabled and an obstruction occurs in the opening or closing movement, the VF7 makes a backward
movement and wait a delay time (Backstep delay).
E.P.S. Slave If enabled, the Emergency Power Supplier will not open the door if the closing signal is activated.
E.P.S. Open Clutch If enabled, the Emergency Power Supplier will only open the car door clutch.
