FERMOD KIT 5000 - Page 11

Kit5000_GB-A
206
≈ 150
A
B
Shoulder
to the top
!
Imperative
!
2150
13
B A
- 11 -
MOTOR
6.4
90° MOTOR MOUNTING See page 26
LEFT SIDE MOTOR MOUNTING See page 28
1 - Right side of the rail, remove the screw of the end bracket (2120/2130 systems).
2150 system : remove the left screw of the end bracket.
2 - Replace it with spacer (B) from small bag (M7).
Fix spacer with a screw, do not drive the screw.
3 - Position spacer (A) on the rail aligning with nut
which is into the upper groove of the rail.
2120 / 2130 / 2150 SYSTEMS
d
e
B
D
E
A
e
M6
E
D
4 - Lift the washer and engage the screw
(D) into slot (d) of motor bracket.
5 - Align spacer (A) and its nut
with hole (e) of motor bracket.
6 - Engage the second screw (E) from small
bag (M7) into hole (e) of motor bracket.
Block the 2 screws.
M7
A
B
C
13
2120-2130
A
B
13
206
≈ 150
