Kit5000_GB-A
CASE N°5 - FERMATIC 3530 / 7530
- 23 -
C
A
B
M8
A B
E
M6
OK
1 - Right side of the rail, remove the butt/opening side (C)
under the end bracket.
2 - Mount butt/opening side (C) with a screw and
spacer (B) from small bag (M8). Block.
3 - Left side of the end bracket, mount spacer (A)
with the second screw from (M8) into the
rst hole of the rail.
Do not block.
4 - Engage a nut and a washer from
small bag (M8) on screw (D).
5 - Tip the motor bracket to engage
the screw (D) in the slot (d) and position the
motor bracket by engaging the screw (E)
into the hole (e) of the bracket.
6 - Push the screw (D) in the slot (d).
Block spacer (A) and nut of the screw (D).
7 - Block the nut of screw (E).
DOOR OPEN
!
e
d
A
B
D
E
24
17
6
!
17
