57EN
cod. 3540000272 - Rev. 01 - 01/2024
1.4 Adjustments
Winter/summer switchover
Press the winter/Summer/off button (detail
7 - fig. 1) until the icon winter (detail 10 -
fig. 1): disappears, the boiler will only deliver
domestic hot water. The frost protection sys-
tem remains activated.
fig. 10
To switch the Winter mode back on, press
the winter/Summer/off button 2 times (de-
tail 7 - fig. 1).
fig. 11
Heating temperature adjustment
Use the heating buttons (details 3 and 4 -
fig. 1) to adjust the temperature from a min.
of 20°C to a max. of 80°C.
fig. 12
DHW temperature adjustment
Use the DHW buttons (details 1 and 2 -
fig. 1) to adjust the temperature from a min.
of 40°C to a max. of 55°C.
B
If little water is drawn
and/or with a high wa-
ter inlet temperature,
the DHW outlet tem-
perature may differ
from the set tempera-
ture.
fig. 13
