FESLEY FED-1000 - Assembly Drawing; Pipe Fitting; Drum Pan Intubation

A B
E
07
B
D
5
G
DC
F
Installation sequence: first install the drum plate, and then install the stand
ASSEMBLY DRAWING
06
Pipe fitting
The pipe fittings are located in a separate small package in the packing box.
Drum pan intubation
Install the drumson the middle horizontal pipe.
H I
X2
