SDE5−...
Festo SDE5−... 0609a English
40
Type SDE5−V1−...SDE5−D2−...SDE5−D10−...
Rated pressure range 0 ... 10 bar 0 ... 2 bar 0 ... −1 bar
Overload pressure (brief ) Max. 15 bar Max. 6 bar Max. 5 bar
Setting range:
 Switching pressure
 Hysteresis (mode 2)
 Hysteresis (mode 0, 1, 3)
0 ... 100 % FS (full scale), (recommended working area 5 .. 95 % FS)
0 ... 100 % FS, (recommended working area 5 .. 95 % FS)
2 % FS (set fixed)
Repeatability of the switching
pressure
Max. ±0.3 % FS
Temperature coefficient 0.5 % FS / 10 K
Ambient temperature range
Storage temperature range
0 ... +50 °C
−20 ... +80 °C
Operating voltage range DC 15 ... 30 V (permitted residual ripple max. 10 %, within the
operating voltage range)
Idling current Max. 30 mA
Switch output
 Max. output current
 Voltage drop
 Capacitive load max. DC
 Switching times (on/off )
Positive switching (PNP)
100 mA
1.5 V
100 nF
2 ms (typical) / 4 ms (max.)
Protective functions Incorrect polarity, short circuit/overload (pulsed), induction
voltage
Protection class IP40 (as per EN 60529)
Protection class III
Max. permitted signal cable
length
30 m
Materials  Housing: PA, POM, PPS (reinforced)
 EDIT button: VMQ
 Cable coating: PUR
 Plug/compressed
air connections: Ms (nickel−plated, chromium−plated)
 Support: PP
Fig.25
