SDE5−...
Festo SDE5−... 0609a English
32
6 Commissioning
Please note
The SDE5−...−..X without EDIT button possesses a factory setting with fixed
switching pressures.
S Read further in the chapter Operation."
The SDE5−...−..X does not require further adjustment.
With all other SDE5−... (with E DIT button 1):
Please note
Unintentional pressing of the EDIT button may cause a modification of the
preset switching pressure.
S Make sure that the EDIT button is only pressed intentionally.
Otherwise the SDE5−... will be set to a switching pressure of 0 bar, for
example if there is no operating pressure.
Definition
Pressure P = relative pressure (also contains vacuum with SDE5−V..−...).
Switching
pressure SP = operating pressure at which the SDE5−... switches
Teach pressure TP = operating pressure at time of programming
Run mode = basic status (achieved by switching the operating voltage
on and off)
SDE5−...
−O−...
−C−...
−O1/O2/O3−...
−C1/C2/C3−...
−FP−...
Setting options −−− −−− Mode selection
Switching pressure setting (teach)
Instruction text Page 29 Page 30 Pages 31 and 32
Fig.13
