6
.
Control via FHPP
71
Festo.P.BE-CMMP-CAM-
SW
-EN en 1105a
6.4.2
Status bytes
SCON
B7
B6
B5
B4
B3
B2
B1
B0
OPM2
OPM1
FCT/MMI
VLOAD
FAULT
WARN
OPEN
ENABLED
Operating mode
acknowledgement
Higher-order
controller
with FCT/MMI
Load
voltage
applied
Malfunction
Warning
Operation
enabled
Drive
enabled
SPOS
B7
B6
B5
B4
B3
B2
B1
B0
REF
STILL
DEV
MOV
TEACH
MC
ACK
HALT
Drive
referenced
Dwell
monitoring
Following
error
Axis moves
Confirmation
of teaching
or sampling
Motion
complete
Ackn
ow
-
ledge start
Halt
SDIR *)
B7
B6
B5
B4
B3
B2
B1
B0
FUNC
FGRP
FNUM
COM2
COM1
ABS
Funct. being
executed
Function group
acknowledgment
Function number
acknowledgment
Control mode
acknowledgment
Absolute /
relative
*) only for dir
ect operation.
In the case of rec
ord selection, the record number is
transferred in
status byte 3. The RSB (
record status byte)
is then transferred i
n status byte 4.
