CMMS-AS-...-G2
Festo – GDCP-CMMS-AS-G2-HW-EN – 1310NH – English 5
Instructions on this documentation
This documentation is intended to help you work safely with the motor controller CMMS-A S-…-G2 and it
describes the functions, start-up procedure and error messages.
Tar get grou p
This documentation is intended exclusively for tec hnicians trained in c ontrol and automation tec hno-
logy, who have experience in installation, commissioning, programming and diagnostics of positioning
systems.
Versions
This documentation refers to the following versions:
– Motor controller CMMS-A S-C4-3A-G2: from Rev. 02
– Firmware: from version 1.4.0.2.6
– Configuration/parameterisation software (Festo Configuration Tool): FCT plug-in
“CMMS-AS”, from version 2.0.0.x
Note
Before using a newer firmware version, check to see if a newer version of the FCT plug-in
or user documentation is available
 Support Portal: http://www.fest o.com/sp.
Service
Please consult your regional Festo contact if you have any technical problems.
Product identification
Rating plate CMMS-AS-…-G2
Meaning
…
CMMS-AS-…-G2
572986
CN98 P0021912
Rev 02
In: 1k(95…250)V AC
(50…60)Hz 4A
Out: 3k(0…Input Voltage)V AC
(0…1000)Hz 4 A
Type designation CMMS-AS-…-G2
Part number e.g. 572986
Revision e.g. Rev 02
Serial number e.g. CN98 P0021912
Input voltage (In) 95 … 250 V AC ±10%
50 … 60 Hz, 4 A
Output voltage (Out) 0 … input voltage V AC
0 … 1000 Hz, 4 A
Tab. 1 Rating plate for CMMS-AS-…-G2 (example)
