Internal layout of CP-E16-M8 (PNP inputs)
1
2
3
PLC/I-PC Ex (e.g. via field bus)
Logic recognition Ex
Green LED Ex
Fig. 1/8: Internal layout of input module CP-E16-M8
24 V +10/-15%
2
Pin 1
Pin 2
Pin 3
3
1
0 V
1. Input module type CP-E16...-M...-...
1-12 CP-E16...-M... 9901b
