Festo CP-E16 Series - Technical Specifications

Technical specifications Negative-switching input modules (NPN)
Type CP-E16N-M8 and type CP-E16N-M12x2
Temperature range:
- operation
- storage/transport
-5
o
C ... + 50
o
C
-20
o
C ... + 70
o
C
Relative humidity 95% non condensing
Protection class as per EN 60 529
Plug connector inserted or fitted
with
protective cap
IP 65
Protection against electric shock as
per EN 60204-1 / IEC 204
(Protection against direct and indirect contact) by
connecting to a PELV power unit (Protected Extra-
Low Voltage)
Electromagnetic compatibility
- interference emission
- resistance to interference
Tested as per EN 55011 limit value class B
Tested as per EN 50082-2
Digital inputs
- Design
16 inputs
as per IEC 1131-2 type
2 inputs 24 V DC
(negative switching)
- Logic level:
ON
OFF
< V
D
-11 V
> V
D
- 5 V
- Current consumption
(at 24 V)
(input current from sensor
to input)
at "logic 0"
typ. 8 mA
- Response delay (at 24 V) typ. 5 ms
Sensor supply max. 0.5 A
(electronic short circuit protection)
Electrical isolation None
Internal current consumption of
electronic components
max. 90 mA
1. Input module type CP-E16...-M...-...
CP-E16...-M... 9901b 1-27
