Festo CP-E16 Series - Input Module Technical Specifications

1.5 Technical specifications
Technical specifications Positive-switching input modules (PNP)
Type CP-E16-M8 and
type CP-E16-M12x2
Type CP-E16-M12x2-5POL
Temperature range:
- operation
- storage/transport
-5
o
C ... + 50
o
C
-20
o
C ... + 70
o
C
Relative humidity 95% non condensing
Protection class as per EN
60 529
Plug connector inserted or
fitted with protective cap
IP 65
Protection against electric
shock as per EN 60204-1 /
IEC 204
(Protection against direct and indirect contact) by
connecting to a PELV power unit (Protected Extra-Low
Voltage)
Electromagnetic compatibility
- interference emission
- resistance to interference
Tested as per EN 55011 limit value class B
Tested as per EN 50082-2
Digital inputs
-Design
16 inputs
as per IEC 1131-2 type 2
inputs
24 V DC
positive-switching
16 inputs
as per IEC 1131-2 type 2
inputs
24 V DC
negative-switching
- Logic level:
ON
OFF
> 11 V
< 5 V
≥ 8.6 V
≤ 6 V
- Current consumption
(at 24 V)
(input current from sensor
to input)
at "logic 1"
typ. 8 mA
at "logic 1"
typ. 6 mA
- Response delay (at 24 V) typ. 5 ms typ. 3 ms
Sensor supply max. 0.5 A
(electronic short circuit protection)
Electrical isolation None
Internal current consumption
of electronic components
< 40 mA max. 90 mA
1. Input module type CP-E16...-M...-...
1-26 CP-E16...-M... 9901b
