Input modules can be connected to one of the follow-
ing:
– the CP connection of the higher-order system (field
bus node, axis interface or Powerbox)
– the CP connection of an output module
– the CP connection of a valve terminal
Further instructions can be found in the appropriate
system manuals.
1. Input module type CP-E16...-M...-...
CP-E16...-M... 9901b 1-21
