Festo CPX-CEC-C1 Electronic Manual

A. Technical appendix
A−3
Festo P.BE−CPX−CEC−E N en 0907NH
A.1 Technical data
Type CPX−CEC−C1
General technical specific. of the CPX terminal see CPX system manual P.BE−CPX−SYS−...
Total number of axes 31
CPU data Processor 400 MHz, 32MB RAM, 32MB flash
Configuration support CoDeSys
Parameterisation CoDeSys
Programming software CoDeSys provided by Festo
Programming language as per IEC 61131−3
LDR, STL, ST, FUN, SFC, also CFC
Program memory 4 MB user program
Protocol CoDeSys Level 2, EasyIP, ModbusTCP, TCP/IP
Device−specific diagnostics  Channel and module−oriented diagnostics
 Undervoltage/short−circuit modules
 Diagnostic memory
Additional functions Diagnostic functions
Motion function for electrical drive units
Baud rate 10/100 bits/s as per IEEE802.3 (10BaseT)
Processing time approx 200 s/1k instructions
LED display (bus−specific) TP: Ethernet connection: link/traffic
LED display (product−specific) RUN: PLC status: started
STOP: PLC status: stopped
ERR: PLC run−time error
PS: Electronic supply, sensor supply
PL: Load supply
SF: System fault
M: Modify/forcing active
