Page 56 Vision Sensor SBSI/SBSC-EN, 8062650 - 1607b - 13/09/2016
Vision Sensor Manual
Once passwords have been assigned and automatic logout has taken place, a login is required e.g. for
sensor configuration. Click on in the tool bar to login and / or (after password entry) to deactivate
password entry for the next session for the selected user group.
If the "deactivate password request" box is ticked, the password will not be requested when the
application is next started.
Fig. 46: Login- button
4.6 SBS – Operating- and configuration software – Vision Sensor
Configuration Studio, all functions
With this programme, you can configure your SBS vision sensor for one or several jobs in six logical
operating steps.
l Jobs (Inspection tasks) (Page 56)
l Alignment (Page 80)
l Detectors (Page 90)
l Output of inspection results (Page 172)
l Result (Page 196)
l Start sensor (Page 198)
Other program functions:
l Trigger settings (Page 200)
l Switching between online and offline mode (Page 200)
l Simulation of jobs (offline mode) (Page 201) using series of images.
l Creating filmstrips (Page 201) Image recording for analysis or simulation purposes. Use of Vision
Sensor Configuration Studio may require password entry (administrator user group). See User
administration / Passwords (Page 54)
l Image recorder (Page 211)
To obtain a continuously updated live image even without trigger, carry out the following (if necessary
temporary) settings:
l Set to free run in "Job/Image acquisition"
l Set to continuous in "Trigger / collect image" User interface and operating procedure
4.6.1 Jobs (Inspection tasks)
A job contains all the settings and parameters required to carry out a certain inspection task.
