Connecting and display elements
1
2
3
4
5
6
7
8
9
0
!
Operating voltage connection, inputs and outputs (CONTROL)
Groove for identification plates (type ISB 6x10)
Green LED, Operating voltage display (POWER)
Valve connection (VALVE)
Red LED, error display (ERROR)
Type plate (see side surface)
TEACH key, teaching the end positions (fixed stops)
Yellow LEDs for position display (A, B)
DIL switch (microswitch) for configuration
Potentiometer connection with cube plug
Earth/ground connection
1
2
!
4
5
6
7
8
9
0
3
English
SPC-10-...
12
9902c
