Festo SPC11 2018-12b English10
Connect an earth cable with sufficient cross-sectional area
to the drive if the drive is not fitted on an earthed machine
stand. Special earthing measures for components other
than those shown here can be found in the System manual
for the SPC11.
Pin assignment on the Control connection
The function of the input I4 and outputs O4 and O5 can be
configured (see system manual for SPC11). The following
tables describe the factory settings.
Output
Pin Description
O1: P.01 13
Supplies a 1-signal when the
drive is in the appropriate
position. Supplies a 1-signal for
50 ms when the drive moves past
the appropriate position.
O2: P.02 12
O3: P.03 11
O4: P.04
1)
10
O5: Error
2)
9 Supplies a 1-signal if there is an
error.
O..: Output
1)
Can be configured; P.04 (factory setting) or Stop
2)
Can be configured; Error (factory setting) or Ready
