Festo SPC11 Series Quick Reference

Festo SPC11 2018-12b English 11
Input Pin Description
I1: P.01 8
1-signal (min. 20 ms)
issues order to move to
appropriate position (when
there is a POS...0-signal at
the other inputs P...)
I2: P.02 7
I3: P.03 6
I4: P.04
1)
5
I5: +/} 4
Controls drive when there
is a 1-signal at Remote
input (see System manual
for SPC11)
I6: - Reset Error
2)
- Enter/Teach/Esc
3
I7: {/– 2
E8: Remote 1 1-signal deactivates
operating buttons and
activates the relevant
inputs (pins 2...4)
I..: Input
1)
Can be configured; P.04 (factory setting) or Stop
2)
0-signal at input E8 (Remote) required
Connection Pin Description
24 V 15
Power supply
0 V 14
