Use the same process to create the routed holes for the side
wall of the cabinet. Set the first hole with the stop pin of the
DOMINO joining machine ...
... and create the others using the cross stop pins. Using the
additional stop, along with the cross stop – is beneficial here,
because the joining machine has a sturdy support surface on
the panel.
Then create the routed holes for the shelves (this process is
similar for carcass sides etc).
Place both side parts on top of each other and mark out the
position where the centre shelf will be. Mark the top and
bottom edge of the shelf (material thickness), not the centre.
For the other routed holes, set the desired hole distance on
the cross stop and position the pin in the first routed hole.
Route the other holes as slots.
